iFlight R1 X5 220mm FPV Freestyle and Racing Frame 4mm Removeable Arms

Taking the same great platform from the R1 X5 220mm, we built something a bit more spacious, and more importantly, stuck the battery on top! This is super helpful for filming/freestyle, it gives the quad more planted flight characteristics

Specifications:

- Chamfred Edge/ Coated carbon plate
- High quality twill carbon fiber.
- 220mm MOTOR TO MOTOR
- 4mm thick arms with stregthened roots to handle the extra weight of the gopro in crashes
- Sturdy 30mm aluminum hexagonal standoffs
- Full set of hardware, including motor screws and a few spares to keep you in the air
- 5" propellers
- Weight:104.7g

Parts List:

- 1x 2mm Bottom Plate
- 1x 2mm Top Plate
- 4x 220 4mm Arms
- 2x 2mm camera side plate
- 8x 30mm Hexagonal Aluminium Standoffs
- 16x M3x12 Button Head Bolt
- 8x M3x6 Button Head Bolt

- 4x M3 Nyloc Nuts
